Automatic Latex Foaming Stirring Generator Machine

Introduction

This advanced automatic one mixing head and two head mixing foaming machine is designed for foaming for all kinds of carpets, artificial fur, rubber, cosmetics and similar products which need to coat latex or other types of slurry or pulp in process, as well as high foam requirements, such as wide carpet coating, non-woven finishing, textile fabric coating and making latex pillow etc. It can efficiently improve the utilization of the coating process and the basic properties of the slurry or pulp. The foams generated are uniform, fine and stable. It has a built-in cooling system.

At present, it has been extensively applied in water-borne PU industry, textile industry and latex pillow industry and other industries.

Parameters for one-head foam machine:

• Overall dimension: 1550x850x1200mm

• Weight: 450kg

• Output: 100-1000kg/h

• Foaming rate: 1:1~1:10

• Application material: water-based pulp/slurry

• Power: 3/N/PE, 380V

• Construction material: stainless steel frame and stainless steel electric box

• Cutting teeth: 2400teeth, rotary speed: 0~360 r/min

• Mechanical sealing: double-end mechanical sealing

Parameters for two-head foam machine:

• Overall dimension: 1550x1700x1200mm

• Weight: 700kg

• Output: 100-1500kg/h

• Foaming rate: 1:1~1:30

• Application material: water-based emulsion

• Power: 3/N/PE, 380V

• Construction material: stainless steel frame and stainless steel electric box

• Cutting teeth: 4800teeth, rotary speed: 0~360 r/min

• Mechanical sealing: double-end mechanical sealing

Machine Characteritics

1. High flow can meet different production travelling speed requirements.
2. The foams generated are uniform, fine and stable.
3. Fully automatic of mixing and foam, can mix more than 2 materials at same time
4. Smart and more precision than ordinary foam equipment.

After sale service

* Video technical support
* Online support
* Free spare parts
* Field installation, commissioning and training
* Field maintenance and repair service
